Manley Ford 4.6L/5.4L (3Valve) Flat Top Forged Aluminum 3.572in Bore 0cc Dome Piston Set - 594020C-8
Upgrade your Ford Modular 4.6L or 5.4L engine with the Manley 3.572" Platinum Series Flat Top Piston Set. Crafted from high-strength 2618 material, these lightweight yet durable pistons ensure maximum horsepower and long service life. Each set includes roundwire locks, tool steel wrist pins, and pressure balance grooves at no extra cost.
- Bore Size: 3.572"
- Rod Length: 5.933"
- Stroke: 3.543 mm
- Flat Top Piston Design
- Combustion Chamber Ratios: 12.78 (42cc), 10.97 (51cc), 10.80 (52cc)
- Includes Ductile Iron and Premium Steel Top Rings
- Fits Ford 4.6L | 5.4L Modular Engines
Manley pistons are machined of high strength 2618 material. Each design is lightweight yet robust enough to deliver long service life. Perfect ring groove to skirt squareness is achieved through our unique "one fixturing" manufacturing method that assures maximum horsepower. Roundwire locks, tool steel wrist pins and pressure balance grooves are included with every set at no additional charge.
Premium Chrome Moly wrist pins are included with the Standard Series and 9310 Alloy wrist pins are included with the Extreme Duty Series.
Specifications: 2 & 4 Valve (Stock Rod Length and Stroke)
- Bore Size: 3.572
- Rod Length: 5.933"
- Stroke (mm): 3.543"
- Comp Distance: 1.220"
- Piston Type: Flat Top
- Combustion Chamber (42cc): 12.78
- Combustion Chamber (51cc): 10.97
- Combustion Chamber (52cc): 10.80
- Piston Wt/Gms: 345
- Included Ring Set
- Ductile Iron Top Rings: 46620-8
- Premium Steel Top Rings: 46620ST-8
- Ford 4.6L | 5.4L Modular
- Compression ratios for 4.6L are calculated at .008" deck clearance, a 8.933" deck height, and a .036" thick compressed head gasket.
| Brand | Manley |
|---|---|
| upc | 807298026312 |
