Manley Ford 4.6L/5.4L SOHC/DOHC (2v/4v)3.582in Bore 18cc Spherical Dish Piston Set - 594230C-8
Upgrade your Ford Modular 4.6L or 5.4L engine with the Manley 3.582" 18cc Platinum Series Spherical Dish Piston Set. Crafted from high-strength 2618 material, these lightweight yet durable pistons ensure maximum horsepower and long service life. Each set includes: - High-strength 2618 material - Perfect ring groove to skirt squareness - Roundwire locks and tool steel wrist pins - Pressure balance grooves - Premium Chrome Moly wrist pins (Standard Series) - 9310 Alloy wrist pins (Extreme Duty Series) - Included ring set: Ductile Iron Top Rings and Premium Steel Top Rings Fitment: Ford 4.6L | 5.4L Modular. Sold as a set of 8.
Manley pistons are machined of high strength 2618 material. Each design is lightweight yet robust enough to deliver long service life. Perfect ring groove to skirt squareness is achieved through our unique "one fixturing" manufacturing method that assures maximum horsepower. Roundwire locks, tool steel wrist pins and pressure balance grooves are included with every set at no additional charge.
Premium Chrome Moly wrist pins are included with the Standard Series and 9310 Alloy wrist pins are included with the Extreme Duty Series.
Specifications: 2 & 4 Valve (Stock Rod Length and Stroke)
- Bore Size: 3.582
- Rod Length: 5.933"
- Stroke (mm): 3.543"
- Comp Distance: 1.220"
- Dome Volume (cc): 18
- Piston Type: Spherical Dish
- Combustion Chamber (42cc): 9.68
- Combustion Chamber (51cc): 8.66
- Combustion Chamber (52cc): 8.56
- Piston Wt/Gms: 393
- Included Ring Set
- Ductile Iron Top Rings: 46630-8
- Premium Steel Top Rings: 46630ST-8
- Ford 4.6L | 5.4L Modular
- Compression ratios for 4.6L are calculated at .008" deck clearance, a 8.933" deck height, and a .036" thick compressed head gasket.
- Sold as a Set of 8
