Wilwood Caliper-D154-Raw/Un-Painted 1.12/1.12in Pistons 0.81in Disc - 120-11875
This Item has limited quantity. Request Quote for item availability.
Please Request Quote for stock status
Wilwood's D154 forged billet caliper is a direct bolt-on, lightweight, high-strength, extreme duty alternative to the OE cast iron calipers that were used on a wide range of factory disc brake equipped mid size GM cars and small trucks beginning in 1978. Use of this caliper can still be found on some GM models as late as the year 2002. The wide spread and affordable availability of D154 calipers and brake pad compounds also made it a popular choice in a number of restricted class competition categories and drum to disc conversions on all types of hot rods and street machines.
There are three piston configurations available for the D154: A large 2.50" single piston, and two two-piston models featuring 1.62/1.62" or 1.12/1.12" pistons. All three calipers utilize stainless steel pistons. Stainless pistons are used to resist corrosion and retard heat transfer from the pads into the caliper body. High temperature, square faced bore seals are used to provide controlled piston retraction and reliable performance from the wider sealing face. This combination of components is a proven performer with long service life and a history of reliable performance in any type of driving environment, including extreme sustained high temperature racing applications. The caliper slide pin holes are fitted with dampening rings to minimize noise from vibration. The caliper is also fitted with bleed screws on both ends to facilitate mounting in any left hand or right hand, front leading mount, or rear trailing mount locations.
Features:
- Piston Count: 2
- Piston Area (in sq.): 1.98
- Piston Type: Stainless
- Dust Boot: No
- Rotor Width (in): 1.04
- Rotor Diameter(in): 12.19
- Pad Area (in sq.): 8.7
- Pad Volume (in cube): 2.9
- Material: Aluminum
- Weight(Lbs): 4.6
- Color: Ano
- Finish: Type III Ano
- Mount Center(in): 5.46
- Mount Side: Universal
- Mount Type: Floating
Unleash Superior Braking Performance with the Wilwood 1.12 | 1.12" Pistons 0.81" Disc Caliper D154 Ano- WILW-120-11875
Experience the pinnacle of braking technology with the Wilwood 1.12 | 1.12" Pistons 0.81" Disc Caliper D154 Ano- WILW-120-11875. Designed for those who demand excellence, this caliper offers unmatched performance and reliability, ensuring your vehicle stops with precision and confidence every time. Whether you're on the track or navigating city streets, this caliper is engineered to deliver exceptional stopping power and durability.
Features and Benefits of the Wilwood 1.12 | 1.12" Pistons 0.81" Disc Caliper D154 Ano- WILW-120-11875
- Precision Engineering: The Wilwood caliper is crafted with meticulous attention to detail, featuring 1.12" pistons that provide balanced and consistent braking force. This ensures that your vehicle maintains stability and control, even under the most demanding conditions.
- Enhanced Stopping Power: With a disc thickness of 0.81", this caliper is designed to maximize friction and heat dissipation, allowing for superior braking performance. This means shorter stopping distances and increased safety for you and your passengers.
- Durable Anodized Finish: The anodized coating not only adds a sleek, high-end appearance but also protects the caliper from corrosion and wear. This ensures long-lasting performance and maintains the caliper's aesthetic appeal over time.
- Lightweight Design: Constructed from high-quality materials, the Wilwood caliper is lightweight yet incredibly strong. This reduces unsprung weight, improving your vehicle's handling and responsiveness.
- Easy Installation: Designed to fit seamlessly into your vehicle's existing brake system, the Wilwood caliper offers straightforward installation. This means less time in the garage and more time enjoying the road.
Upgrade your vehicle's braking system with the Wilwood 1.12 | 1.12" Pistons 0.81" Disc Caliper D154 Ano- WILW-120-11875 and experience the difference that precision engineering and advanced technology can make. Whether you're a performance enthusiast or simply looking to enhance your vehicle's safety, this caliper is the perfect choice. Trust in Wilwood's legacy of excellence and take your driving experience to the next level.
| Brand | Wilwood |
|---|---|
| upc | 889545100204 |
