Garrett GT35R THWA 0.63 A/R T3 (int w/g - 5 bolt out) (Ni-Resist) - 771300-0003

Special Price $458.02 Regular Price $552.73
sku
grt771300-0003
Free Shipping Banner
Stock is low or unavailable.
Please Request Quote for stock status
Rev up your engine's performance with the Garrett GT35R / GTX35R Turbine Housing Kit. Designed for precision and power, this kit is perfect for automotive enthusiasts seeking enhanced turbo efficiency. - **Versatile Compatibility**: Fits GT35R, GTX35R Gen I, and Gen II models. - **Optimal Performance**: 0.63 A/R T3 housing for improved airflow and response. - **Integrated Wastegate**: Ensures efficient boost control and reliability. - **Durable Construction**: Built to withstand high temperatures and pressures. - **Easy Installation**: 5-bolt outlet design simplifies the setup process. Upgrade your turbo system with this high-quality turbine housing kit and experience superior performance on the road.

GT3582R Turbocharger

Horsepower: 400 - 675

Displacement: 2.0L - 4.5L

Important product information: Garrett Performance Kits are professional aftermarket products only designed for certain racing vehicles driven on particular racing tracks and shall only be used on racing vehicles that will never be driven on public roads or highways. Garrett Performance Kits are not legal for the use in vehicles on public roads or other roads to which public road law applies. Any vehicle modifications using Garrett Performance Kits are AT YOUR OWN RESPONSIBILITY and AT YOUR OWN RISK. Only use Garrett Performance Kits in compliance with all applicable laws, regulations, and ordinances (including but not limited to emission, noise, operating license, performance, safety, and type-approval aspects). A vehicle modification using Garrett Performance Kits may particularly affect or void a vehicle’s warranty, operating license or type-approval. Moreover, only use Garrett Performance Kits in compliance with all applicable racing and racing track provisions. It is YOUR OWN RESPONSIBILITY AND RISK to ensure that your Garrett Performance Kit fits your vehicle and area of application. YOU MUST ENSURE LAWFUL AND SAFE OPERATIONS AT ANY TIME. You should particularly consult the owner’s manual and service manual of your vehicle. You should also contact your vehicle’s manufacturer to determine what effects modifications may have on important aspects such as safety, warranty, performance, etc. Only install and use Garrett Performance Kits if you have fully read and understood this important safety information and if you fully agree with the terms and conditions set forth therein.

Features

  • ORIGINAL GT SERIES AERODYNAMICS
  • 61mm TURBOCHARGER COMPRESSOR OPTION
  • INTERNALLY WASTEGATED TURBINE HOUSING
  • NON WASTEGATED TURBINE HOUSINGS AVAILABLE
  • BALL BEARING CONFIGURATION WITH WATER COOLED CHRA
  • V-BAND TURBINE HOUSING OPTIONS

GT3582R

Reference Data

The latest Garrett technologies featuring many advanced features.


GT3582R Compressor Turbine
Inducer Exducer Trim A/R Inducer Exducer Trim
HP: 400-675              Disp: 2.0L-4.5L 61mm 82mm 56 0.70 68mm 62mm 84
Supercore PN PN
836033-5002S
Turbine Kits: GT30 PN A/R Inlet Outlet Wastegate Divided
Interchangeable with GT, GTX Gen I,
and GTX Gen II 35 Series Supercores
740902-0012 0.63 T3 V-Band Free Float N
740902-0011 0.82 T3 V-Band Free Float N
740902-0010 1.06 T3 V-Band Free Float N
740902-0018 0.63 T4 V-Band Free Float N
740902-0017 0.82 T4 V-Band Free Float N
740902-0016 1.06 T4 V-Band Free Float N
740902-0033 0.61 V-Band V-Band Free Float N
740902-0032 0.83 V-Band V-Band Free Float N
740902-0031 1.01 V-Band V-Band Free Float N
PN A/R Inlet Outlet Wastegate Divided
Wastegated turbine assembly does not include bolts, clamps, or actuator 771300-0003 0.63 T3 5 Bolt Wastegated N
771300-0002 0.82 T3 5 Bolt Wastegated N

GT3582R

Download Section

The latest Garrett technologies featuring many advanced features.

File Name Link View
Configuration Guide Download View
File Name Link View
Compressor Map Download View
Exhaust Flow Chart Download View
Product Photo Download View
Flange Diagram Download View
Speed Sensor Kit Installation Instruction Download View

GT3582R

Compressor Map & Exhaust Flow Chart

The latest Garrett technologies featuring many advanced features.

Compressor Map

Exhaust Flow Chart

About Garrett® GT Series Turbochargers

Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.

More Information
Brand Garrett Motion
