Garrett GBC14-200 Club Line Turbocharger 0.45 O/V 3-Bolt / 4-Bolt - Internal WG - 896051-5004S

Special Price $632.85 Regular Price $770.73
sku
grt896051-5004S
Free Shipping Banner
More than 2 in stock
Unleash the full potential of your engine with the Garrett GBC14-200 Turbocharger. Designed for efficiency and power, this turbocharger features a 0.45 O/V ratio and a robust wastegate system, ensuring optimal performance. Its versatile 3-bolt and 4-bolt configuration allows for easy installation, making it a perfect upgrade for enthusiasts seeking enhanced speed and reliability. Crafted with precision, the Garrett GBC14-200 delivers a seamless boost in horsepower, transforming your driving experience. Elevate your vehicle's performance with this high-quality turbocharger, engineered to meet the demands of both street and track.

Garrett Boost | Club Line GBC14-200 34MM

Horsepower: 140 - 200

Displacement: 0.4L - 1.0L

Important product information: Garrett Performance Kits are professional aftermarket products only designed for certain racing vehicles driven on particular racing tracks and shall only be used on racing vehicles that will never be driven on public roads or highways. Garrett Performance Kits are not legal for the use in vehicles on public roads or other roads to which public road law applies. Any vehicle modifications using Garrett Performance Kits are AT YOUR OWN RESPONSIBILITY and AT YOUR OWN RISK. Only use Garrett Performance Kits in compliance with all applicable laws, regulations, and ordinances (including but not limited to emission, noise, operating license, performance, safety, and type-approval aspects). A vehicle modification using Garrett Performance Kits may particularly affect or void a vehicle’s warranty, operating license or type-approval. Moreover, only use Garrett Performance Kits in compliance with all applicable racing and racing track provisions. It is YOUR OWN RESPONSIBILITY AND RISK to ensure that your Garrett Performance Kit fits your vehicle and area of application. YOU MUST ENSURE LAWFUL AND SAFE OPERATIONS AT ANY TIME. You should particularly consult the owner’s manual and service manual of your vehicle. You should also contact your vehicle’s manufacturer to determine what effects modifications may have on important aspects such as safety, warranty, performance, etc. Only install and use Garrett Performance Kits if you have fully read and understood this important safety information and if you fully agree with the terms and conditions set forth therein.

Features

  • Club Line is a product engineered for small engine displacements. This includes powersports, personal watercraft, and automobiles. These turbochargers feature internally wastegated turbine housings and journal bearing rotating groups. GBC stands for GARRETT BOOST | CLUB LINE. The first two numbers indicate the turbo frame size. The larger the number the larger the turbine wheel. The numbers following the dash indicate the peak potential flywheel horsepower rating.GBC14-200
    •34mm compressor inducer | 46mm compressor exducer
    •Supports up to 200 horsepower
    •Forged Fully-Machined Compressor Wheel
    •Journal Bearing Rotating Group
    •Internally wastegated turbine housing
    •Engineered for small displacement engines including powersports, personal watercraft and automobiles
    • Read About Turbo System Optimization: A guide to setting up your turbocharger
    • The maximum power stated for each turbocharger has been calculated based strictly on choke flow of the compressor map (total turbo capability), which represents the potential flywheel power. Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration. Please consult with your local distributor before making a purchase.

GBC14-200 34mm

Reference Data

The latest Garrett technologies featuring many advanced features.

GBC14-200 Compressor Turbine
HP: 140-200              Disp: 0.4L-1.0L Inducer Exducer A/R Inducer Exducer Trim A/R
Turbo PN: 896051-5004S 34mm 46mm 0.52 39mm 36mm 84 0.45

GBC14-200 34mm

Download Section

The latest Garrett technologies featuring many advanced features.

File Name Link View
Configuration Guide Download View
File Name Link View
Compressor Map Download View
Exhaust Flow Chart Download View
Product Photo Download View
Flange Diagram Download View
Speed Sensor Kit Installation Instruction Download View

GBC14-200 34mm

Compressor Map & Exhaust Flow Chart

The latest Garrett technologies featuring many advanced features.

Compressor Map

Exhaust Flow Chart

Compressor Aero

Forged, fully-machined compressor wheels with advanced aero is offered in 34mm inducer size and 46mm exducer. GBC14-200 can support from 140-200 350 horsepower. The compressor wheel is a 55 trim and the Compressor housing A/R is 0.52 A/R. This turbocharger can support up to 22 lbs/min of airflow and up to 2.8 pressure ratio.

Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration. The target power represented has been calculated based strictly on choke flow of the compressor map (total turbo capability), which represents the potential flywheel power.

Journal Bearing Rotating Group

The oil cooled center housing features the latest generation of journal bearing rotor group.

Internally Wastegated

Club Line turbochargers are fully assembled with an internally wastegated turbine housing. Garrett’s technicians calibrate the actuator for optimum performance, eliminating any need for adjustment. Club Line turbochargers are calibrated with a 0.5 bar actuator. Actuators with higher pressure settings (1.0, 1.5 bar) are available for individual purchase.

Turbine Housing

The GBC14-200 turbine housing inlet can be machined to V-band with OD of 2.24” (57mm) for use with 1.75” tubing.

More Information
More Information
Brand Garrett Motion
