Gates 2013-14 Arctic Cat Wildcat 1000 951cc G-Force RedLine CVT Belts - 28R3636
Introducing the Gates G-Force Redline CVT Belt - GATE-28R3636, the next generation in Continuously Variable Transmission belts. Engineered for extreme off-road performance, this belt offers superior acceleration, higher top speeds, and reduced energy loss. Key benefits include:
- Enhanced durability and wear resistance
- Greater heat resistance and recovery
- Optimized Ethylene Elastomeric (EE) compound for higher torque
- Tested in extreme conditions and on race vehicles
- Double notched construction with Aramid cord material
Gates G-Force RedLine CVT Belts are the first of a new generation of Continuously Variable Transmission (CVT) belts. Gates innovative design results in better acceleration, higher top speeds, less speed ratio and energy loss in extreme off-road environments.
Improved durability, crack- and wear-resistant means a longer-lasting, higher-performance power transmission belt for the most demanding applications
Greater heat resistance and recovery, even under severe duty cycles
Optimized, patented Ethylene Elastomeric (EE) compound maximizes axial stiffness enabling belts to run at higher continuous torques or loads
Tested under extreme conditions in controlled environments as well as on race vehicles
Features:
- Type: Power Sport Specialty High Performance CVT Belt
- Section: RVS-R
- Angle: 23
- Top Width (in): 1.278
- Top Width (mm): 33
- Pitch Width (in): 1.211
- Pitch Width (mm): 30.8
- Outside Circumference (in): 37.532
- Outside Circumference (mm): 953
- Pitch Length (in): 36.358
- Pitch Length (mm): 923.5
- Thickness (in): .567
- Thickness (mm): 14.4
- Construction: Double Notched
- Notched: Yes
- Belt Material: EPDM
- Cord Material: Aramid
- Fabric Bottom: Yes
- Color: Black
- OE Comparison Rating: OE Improved
| Brand | Gates |
|---|---|
| upc | 770075760382 |
