TEIN STREET BASIS Z Coilover Kit Lexus GS300 JZS160L FR 1998-2005 USA- GST76-81SS2
The Tein STREET BASIS Z Coilover System combines affordability and comfort packaged into a masterfully constructed suspension system. These coilovers utilize a Twin-Tube setup that when compared to the regular mono-tube systems, these twin-tube systems attain longer stroke with a smaller repulsive force, resulting in increased ride comfort. Thanks to this unique characteristic, you can negotiate gaps and bumps steadily on rough roads, meaning a smooth ride at low speed and stability at high speeds.
Front Specifications:
- Damping Force Adjustment: N
- Full-Length Ride-Height Adjustable: N
- Upper Mount: OEM
- Recommended Ride Height (mm): -40
- Recommended Ride Height (inch): -1.6
- Ride Height Adjustable Range:
- Max Low (mm): -89
- Max Low (inch): -3.5
- Max High (mm): -8
- Max High (inch): -0.3
- Recommended Low (mm): -50
- Recommended Low (inch): -2
- Recommended High (mm): -30
- Recommended High (inch): -1.2
- Spring
- Rate (kgf/mm): 10
- Rate (lbs/in): 560
- SP PART#S8T60-13100
- Free Length (mm): 250
- Damping Force Adjustment: N
- Full-Length Ride-Height Adjustable: N
- Upper Mount: OEM
- Recommended Ride Height (mm): -40
- Recommended Ride Height (inch): -1.6
- Ride Height Adjustable Range:
- Max Low (mm): -89
- Max Low (inch): -3.5
- Max High (mm): -18
- Max High (inch): -0.7
- Recommended Low (mm): -50
- Recommended Low (inch): -2
- Recommended High (mm): -30
- Recommended High (inch): -1.2
- Spring:
- Rate (kgf/mm): 9
- Rate (lbs/in): 504
- SP PART#BD090-13225
- Free Length (mm): 225
- I.D. (mm): ID70 - ID90
- Year: 1998-2005
- Make: Lexus
- Model: GS300
- Drivetrain: FR
- Chassis: JZS160L
- Motor Size: 3000
- Vehicle Region: USA
- Steel Construction
- Twin Tube internal construction
- Thread Type Ride Height Adjustment
- Utilizes OEM Mounts
- 16 way adjustable dampers, compression and rebound combined
- High Durability and Reliability
- Anodized brackets with Teflon coated shock body for heavy duty rust prevention
| Brand | TEIN |
|---|
