Bilstein 10-22 Lexus GX460 / 02-22 Toyota 4Runner B8 5160 Series Rear Right 46mm Shock Absorber - 25-325096
Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.
46mm Monotube Shock Absorber
Features
- Billet Reservoir Clamp Included: Yes
- Collapsed Length (IN): 14.50
- Body Design: Smooth Body (Non-Coilover)
- Collapsed Length (MM): 368.3
- Spring Seat Included: No
- Finish: Zinc Plated
- Series: B8 5160
- Extended Length (IN): 23.50
- Title: Bilstein Shock Absorbers
- California Proposition 65: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
- Internal Design: Monotube
- Upper Mount Type: Stem
- Lower Mount Type: Eye 19.25mm
- Boot Included: Black Bellows
- Body Diameter (ID): 46mm
- Extended Length (MM): 597.0
- Reservoir: Yes
- Adjustable Damping: Non-Adjustable
Notes:
Fits position: Rear Right
Bilstein 10-22 Lexus GX460 / 02-22 Toyota 4Runner B8 5160 Series Rear Right 46mm Shock Absorber - 25-325096 aftermarket shock absorber
This Bilstein B8 5160 Series rear right shock absorber is a direct-fit remote reservoir component for lifted trucks and SUVs. It uses a monotube internal design and vehicle-specific digressive valve settings to support consistent performance under demanding use.
SKU: bil25-325096
Key Benefits
- Remote reservoir design increases cooling capacity versus a traditional shock absorber.
- Additional wheel travel support helps optimize performance for lifted truck applications.
- Monotube construction promotes consistent, fade-free damping during extended driving.
- Velocity-sensitive digressive valve settings tuned for each specific application.
- 360-degree swivel banjo hose fitting supports flexible, clean reservoir routing.
- Billet reservoir mount delivers a low-profile installation where applicable.
- Built to increase overall durability for harsh off-road environments.
Specifications
- Position: Rear Right
- Series: B8 5160
- Internal Design: Monotube
- Body Design: Smooth Body (Non-Coilover)
- Body Diameter (ID): 46mm
- Reservoir: Yes
- Adjustable Damping: Non-Adjustable
- Finish: Zinc Plated
- Upper Mount Type: Stem
- Lower Mount Type: Eye 19.25mm
- Collapsed Length: 14.50 in (368.3 mm)
- Extended Length: 23.50 in (597.0 mm)
- Boot Included: Black Bellows
- Billet Reservoir Clamp Included: Yes
- Spring Seat Included: No
- California Proposition 65: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Designed around the B8 5160 remote reservoir layout, this rear right unit combines a 46mm monotube shock body with a reservoir for improved heat management and controlled damping. The included clamp and bellows boot help complete a tidy fitment while maintaining the intended suspension performance characteristics.
| Brand | Bilstein |
|---|
