Bilstein 8125 Series 24in Extended Length 16in Collapsed Length 60mm Monotube Shock Absorber - 33-225494
Bilstein B8 8125 coilovers are engineered for the serious off-road enthusiast, available in both 46mm (2 inch) and 60mm (2.65 inch) sizes. Designed for use with dual-rate springs and available in a wide range of travel lengths, these performance coilovers are perfect for custom coilover suspension applications. Equipped with a competition designed, 3-stage seal pack, these coilovers withstand the harshest off-road environments. All B8 8125 coilovers include a 22mm hard chromed, case hardened piston rod which provides exceptional tensile strength and resistance to sand blasting and rock chipping. Incorporated remote reservoir combined with a high-temp hose provides consistent fade free performance under conditions of intense heat. The zinc coated threaded body allows for quick ride height adjustments and spring changes. Bilstein B8 8125 coilovers are completely owner rebuildable with replacement parts available from Bilstein. All components are machined to precise tolerances and made in the USA to insure high quality.
60mm Monotube Shock Absorber
Features
- Extended Length (IN) Rounded: 24
- Compression @0.52m/s: 1100
- Rebound @0.52m/s: 3700
- Collapsed Length (IN) Rounded: 16
- Collapsed Length (MM): 406.4
- Upper Mount Type: Eye .5x1.5in
- Reservoir: Yes
- Mount Type: Eye-to-Eye
- Series: B8 8125
- Extended Length (MM): 609.6
- Lower Mount Type: Eye .5x1.5in
- Optional Reservoir Clamp: B4-KT1-Z292A00
- Internal Design: Monotube
- Body Diameter (ID): 60mm
- Collapsed Length (IN): 16.00
- Finish: Zinc Plated
- Body Design: Threaded Body Screw Top (Coilover)
- California Proposition 65: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
- Title: Bilstein Shock Absorbers
- Extended Length (IN): 24.00
Notes:
Universal Fitment: These products should work with your vehicle as they are universal for fitment. We do recommend the customer researches and does due diligence regarding application. This should help confirm that this will work for your vehicle.
Bilstein B8 8125 coilovers are engineered for the serious off-road enthusiast, available in both 46mm (2 inch) and 60mm (2.65 inch) sizes. Designed for use with dual-rate springs and available in a wide range of travel lengths, these performance coilovers are perfect for custom coilover suspension applications. Equipped with a competition designed, 3-stage seal pack, these coilovers withstand the harshest off-road environments. All B8 8125 coilovers include a 22mm hard chromed, case hardened piston rod which provides exceptional tensile strength and resistance to sand blasting and rock chipping. Incorporated remote reservoir combined with a high-temp hose provides consistent fade free performance under conditions of intense heat. The zinc coated threaded body allows for quick ride height adjustments and spring changes. Bilstein B8 8125 coilovers are completely owner rebuildable with replacement parts available from Bilstein. All components are machined to precise tolerances and made in the USA to insure high quality.
60mm Monotube Shock Absorber
Features
- Extended Length (IN) Rounded: 24
- Compression @0.52m/s: 1100
- Rebound @0.52m/s: 3700
- Collapsed Length (IN) Rounded: 16
- Collapsed Length (MM): 406.4
- Upper Mount Type: Eye .5x1.5in
- Reservoir: Yes
- Mount Type: Eye-to-Eye
- Series: B8 8125
- Extended Length (MM): 609.6
- Lower Mount Type: Eye .5x1.5in
- Optional Reservoir Clamp: B4-KT1-Z292A00
- Internal Design: Monotube
- Body Diameter (ID): 60mm
- Collapsed Length (IN): 16.00
- Finish: Zinc Plated
- Body Design: Threaded Body Screw Top (Coilover)
- California Proposition 65: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
- Title: Bilstein Shock Absorbers
- Extended Length (IN): 24.00
Notes:
Universal Fitment: These products should work with your vehicle as they are universal for fitment. We do recommend the customer researches and does due diligence regarding application. This should help confirm that this will work for your vehicle.
| Brand | Bilstein |
|---|---|
| upc | 651860754703 |
