Mishimoto Universal Air-To-Water Intercooler Single Pass (1000hp) - Opposite Side Inlet/Outlet - MMINT-A2W-SPR-2
Keeping air intake temperatures low is the key to decreasing the impact of heat soak, reducing detonation, and producing consistent power output. As a result, Intercooler systems have evolved substantially over the last decade, bringing liquid-to-air intercoolers into popularity. To help bring the compact efficiency of air-to-water intercooling to your project, Mishimoto has developed a full lineup of high-performance air-to-water intercoolers.
Our air-to-water intercoolers are available in single or dual-pass coolant flow configurations, each with multiple bar-and-plate core sizes and your choice of same-side or opposite-site outlets. These intercoolers support builds producing up to 1500 horsepower.
When it comes to our intercoolers construction, robust is an understatement. Each intercooler features 5mm-thick cast-aluminum end tanks that are custom engineered for superb airflow, reducing overall pressure drop through the cooler. These tanks are professionally TIG-welded to our core, resulting in a pressure tolerance of up to 100 psi of boost. In addition, our intercooler design features unique CNC-machined ribbed inlet and outlet coupler connections, ensuring maximum grip between couplers and intercooler piping.
Mounting and plumbing your air-to-water system can seem like a daunting task, but Mishimoto has made both tasks easy by incorporating -12ORB coolant ports into the core and providing a sturdy 1/8" thick steel universal mounting bracket. Adapting to your specific coolant line choice is easy with the Mishimoto -12ORB Aluminum Fitting selection.
Features:
- Highly efficient air-to-water design delivers effective cooling in a compact package
- Bar-and-plate core provides durability and efficient cooling for vehicles up to 1500hp
- Cast-aluminum end tanks are custom engineered to yield superb airflow and durability
- Available in multiple core sizes, end tank configurations, and single or dual pass coolant flow
- All-aluminum professionally TIG-welded construction rated to 100psi of boost pressure
- CNC-machined ribbed airflow inlet/outlet produces secure coupler connections
- Sleek, subtle, and durable micro-wrinkle black powder coat finish
- -12ORB coolant ports provide leak-free line connections
- Includes robust 1/8" thick steel mounting bracket and hardware
- Abundant coolant line options with Mishimoto's -12ORB Aluminum Fittings
- Pair with a Mishimoto Air-to-Water Heat Exchanger for the ultimate efficiency in your charge-air cooling setup
- Multiple core sizes to choose from to fit the needs of your project
- Mishimoto Lifetime Warranty
- (1) Mishimoto Air-To-Water Intercooler
- (1) Mounting Bracket
- (4) Mounting Bracket Bolts M6X1.0 X 16mm
- Mishimoto Lifetime Warranty
- Weight: 25lbs
- Coating: Powder Coated
- Tank Wall Thickness: 5mm
- Max Rec. PSI: 100
- Outlet: 500HP: 2.75
1000HP: 3.00
1500HP: 3.50 - Inlet: 500HP: 2.75
1000HP: 3.00
1500HP: 3.50 - Core Size: 500HP: 9.79 X 3.93 X 3.93
1000HP: 12.00 X 4.92 X 4.92
1500HP: 12.00 X 5.90 X 5.90 - Overall Length: Same Side Inlet/Outlet: 13.61
Opposite Side Inlet/Outlet: 14.13 - Overall Height: 500HP: 9.25
1000HP: 10.75
1500HP: 12.37 - Overall Width: 500HP: 3.93
1000HP: 4.92
1500HP: 5.90
Unleash Unmatched Performance with the Mishimoto 1000 HP Air-to-Water Intercooler Opposite Side Single-Pass Coolant Flow- MISH-MMINT-A2W-SP
Elevate your vehicle's performance to new heights with the Mishimoto 1000 HP Air-to-Water Intercooler Opposite Side Single-Pass Coolant Flow- MISH-MMINT-A2W-SP. Designed for those who demand the best, this intercooler is engineered to deliver exceptional cooling efficiency and power gains, making it an essential upgrade for high-performance enthusiasts.
Features and Benefits of the Mishimoto 1000 HP Air-to-Water Intercooler Opposite Side Single-Pass Coolant Flow- MISH-MMINT-A2W-SP
- High Horsepower Capacity: Capable of supporting up to 1000 horsepower, this intercooler is perfect for high-performance applications, ensuring your engine runs cooler and more efficiently.
- Advanced Cooling Technology: The air-to-water design provides superior cooling compared to traditional air-to-air intercoolers. By using water as a cooling medium, it effectively reduces intake air temperatures, resulting in increased power and improved engine reliability.
- Opposite Side Single-Pass Coolant Flow: This innovative design maximizes cooling efficiency by allowing coolant to flow in a single pass across the core, ensuring optimal heat transfer and consistent performance.
- Durable Construction: Built with high-quality materials, the Mishimoto intercooler is designed to withstand the rigors of high-performance driving. Its robust construction ensures long-lasting durability and reliability.
- Compact and Versatile Design: The compact size of this intercooler allows for easy installation in a variety of vehicles, making it a versatile choice for any performance build.
- Improved Engine Efficiency: By reducing intake air temperatures, this intercooler helps improve combustion efficiency, leading to better fuel economy and reduced emissions.
- Enhanced Throttle Response: Experience quicker throttle response and reduced turbo lag, thanks to the efficient cooling capabilities of the Mishimoto intercooler.
The Mishimoto 1000 HP Air-to-Water Intercooler Opposite Side Single-Pass Coolant Flow- MISH-MMINT-A2W-SP is more than just a performance upgrade; it's a commitment to excellence. Whether you're pushing your vehicle to its limits on the track or simply seeking to enhance your daily driving experience, this intercooler delivers the performance and reliability you need.
Invest in the Mishimoto intercooler and experience the difference in power, efficiency, and overall driving enjoyment. With its advanced features and high-end construction, it's the perfect choice for those who refuse to compromise on quality and performance.
| Brand | Mishimoto |
|---|---|
| upc | 840197701577 |
